NOMS-01 SPO2 Parameter Module

Short Description:

Narigmed’s proprietary software algorithm has been carefully developed and combined with proprietary probes and monitoring systems to meet the measurement needs of animals of different sizes. No matter when measuring weak perfusion parts, the system can also provide high-precision data analysis and can quickly and accurately produce values.

Send email to us

Product Detail

Product Tags

Product Attributes

Product Name	NOMS-01 Spo2 Parameter Module
Size	31mm18mm3mm
Wiring methods	Bonding pad
Application	Adult/Pediatric/Neonatal
Spo2 measurement range	35%~100% ultra wide range
Spo2 measurement accuracy	±2%(70%~100%)
PR measurement accuracy	The greater of ±2bpm and+2%
PI display range	0.02%-20%
Anti-motion performance(1~4Hz,1~2cm fixed/random frequency disturb)	Spo2:+3% PR: the greater of +4bpm and+4%
Low perfusion performance	Spo2 ±2%, PR ±2bpm
Supporting low perfusion measurement	Can be as low as 0.025%with probe of Narigmed
Waveform output	Bar diagram/Pulse wave
Communication mode	Bar diagram/Pulse wave
Probe off detection/Probe failure detection	YES
Alarm management	YES
Power supply	Type-C,5V DC/＜45mA
Breathing measurement(RR)	4-70rpm
PR measurement range	25~250bpm ultra wide range
